Hager Flush Mounting Enclosures (Opaque Door) - 48 Modules

Hager Flush Mounting Enclosures (Opaque Door) - 48 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Opaque Door) - 54 Modules

Hager Flush Mounting Enclosures (Opaque Door) - 54 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Opaque Door) - 72 Modules

Hager Flush Mounting Enclosures (Opaque Door) - 72 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 12 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 12 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 18 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 18 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 24 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 24 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 36 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 36 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 48 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 48 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 54 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 54 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Flush Mounting Enclosures (Transparent Door) - 72 Modules

Hager Flush Mounting Enclosures (Transparent Door) - 72 Modules   Technical Characteristics Architecture Fixing mode: flush-mounting Compatibility Compatible with DIN rail mounting: yes Cover, door Cover type: Closed (plain) Transparent cover or door: Yes/No Cover type: Door Door locking: without Type of door closing: Latch Number of doors: 1 Interlockable: yes Materials RAL colour: RAL 9010 - Pure white Colour: white   Material: Plastic Enclosure material:...

Hager Hager Motion detector 200°

Architecture Fixing mode: surface-mounting Functions Operation mode switch: no can be used as a single unit, main device or extension unit with 2 operating modes: time- and light-dependent switch on or pulse mode Main electrical features Frequency: 50/60 Hz Rated operational voltage Ue: 230 V Voltage Operating voltage: 230 V~ Electric current Switching current (ohmic): max. 16 A Power Max. power with fluo uncompensated lamps:...

Hager Hager Movement Detector 360° Flush Mounted (Normally Open Contact)

Architecture Fixing mode section make Functions Function can only be used as individual unit Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Dimensions Height of installed product 15.5 mm Length 75 mm Width of installed product 19 mm Frequency Frequency 50;60 Hz Power Halogen switching capacity 230V 0 / 2300 W Max. power with fluo uncompensated lamps 1000 VA Incandescent bulb...

Hager Hager Movement Detector 360° Surface Mounted

Architecture Fixing mode surface-mounting Functions Function can only be used as individual unit Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Dimensions Height of installed product 50 mm Length 100 mm Frequency Frequency 50;60 Hz Power Halogen switching capacity 230V 0 / 2300 W Max. power with fluo uncompensated lamps 1000 VA Incandescent bulb power 0 / 2300 W Capacity Breaking...

Hager Insulated Busbar 1P - 63A (13M)

Architecture Number of poles 1 P Type of pole 1 P Main electrical features Rated current 63 A Voltage Max operating voltage 230 V Rated impulse withstand voltage 4 kV Dimensions Length 228 mm Capacity Number of modules 13 Materials Colour Brown | Blue Connection Connection cross-sect. rigid cable 10mm² Type of connection with screw Standards European directive WEEE concerned

Hager Insulated Busbar 2P - 63A

Architecture Number of poles 2 P Main electrical features Rated current 63 A Voltage Max operating voltage 400 V Rated impulse withstand voltage 4 kV Dimensions Length 210mm | 420 mm Capacity Number of modules 12 | 24 Materials Colour stone grey Connection Connection cross-sect. rigid cable 10mm² Type of connection with screw Standards European directive WEEE concerned

Hager Insulated Busbar 3P - 63A

Architecture Number of poles 3 P Main electrical features Rated current 63 A Voltage Max operating voltage 400 V Rated impulse withstand voltage 4 kV Dimensions Length 420 mm Capacity Number of modules 24 Materials Colour stone grey Connection Connection cross-sect. rigid cable 10mm² Type of connection with screw Standards European directive WEEE concerned

Hager Insulated Busbar 4P

Architecture Number of poles 4 P Main electrical features Rated current 63 A | 80 A Voltage Max operating voltage 400 V Rated impulse withstand voltage 4 kV Dimensions Length 420 mm | 1000mm Capacity Number of modules 24 | 56 Materials Colour stone grey Connection Connection cross-sect. rigid cable 10mm² Type of connection with screw Standards European directive WEEE concerned

Hager Modular Switch 2P - 125A

Hager Modular Switch 2P - 125A   Architecture Neutral position without neutral Number of poles 2 P Type of pole 2 P Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed product...

Hager Modular Switch 2P - 32A

Hager Modular Switch 2P - 32A   Architecture Neutral position without neutral Number of poles 2 P Type of pole 2 P Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed product...

Hager Modular Switch 2P - 40A

Hager Modular Switch 2P - 40A   Architecture Neutral position without neutral Number of poles 2 P Type of pole 2 P Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed product...

Hager Modular Switch 2P - 63A

Hager Modular Switch 2P - 63A   Architecture Neutral position without neutral Number of poles 2 P Type of pole 2 P Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed product...

Hager Modular Switch 2P - 80A

Hager Modular Switch 2P - 80A   Architecture Neutral position without neutral Number of poles 2 P Type of pole 2 P Main electrical features Rated operational voltage Ue 230 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed product...

Hager Modular Switch 4P - 100A

Hager Modular Switch 4P - 100A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...

Hager Modular Switch 4P - 125A

Hager Modular Switch 4P - 125A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...

Hager Modular Switch 4P - 25A

Hager Modular Switch 4P - 25A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...

Hager Modular Switch 4P - 32A

Hager Modular Switch 4P - 32A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...

Hager Modular Switch 4P - 40A

Hager Modular Switch 4P - 40A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...

Hager Modular Switch 4P - 63A

Hager Modular Switch 4P - 63A Technical characteristics Architecture Neutral position without neutral Number of poles 4 P Type of pole 4 P Main electrical features Rated operational voltage Ue 400 V Frequency 50;60 Hz Rated current Voltage Rated insulation voltage 440 V Rated impulse withstand voltage 4000 V Dimensions Depth of installed product 68 mm Height of installed product 83 mm Width of installed...
