• Hager Steel Enclosure 500x400x200 mm) + Chassis (500x400 mm) 48 Modules
  • Hager Steel Enclosure 500x400x200 mm) + Chassis (500x400 mm) 48 Modules
1 2

Hager Steel Enclosure 500x400x200 mm) + Chassis (500x400 mm) 48 Modules

Hager Steel Enclosure 500x400x200 mm) + Chassis (500x400 mm) 48 Modules

Rs 13,525.00
Rs 13,525.00
Sale Sold out
Tax included.

Type : Steel Enclosure

SKU : HGFL112A + HGFL992A

Collections : Distribution Boxes & Enclosures for Breakers, Hager,

Availability : Out Of Stock

Shipping & Returns

Delivery Available on this product.
We deliver all Mauritius domestic orders within 2-5 business days!

View full details

Hager Steel Enclosure (500x300x200 mm) + Chassis (500x300 mm)

Technical properties

Functions
  • Cover with overpressure release
    No
Configuration
  • Number of modules
    48
Compatibility
  • Suitable for lightning protection
    No
Electric current
  • Rated current
    630 A
Dimensions
  • Insertion depth
    200 mm
  • Depth of installed product
    200 mm
  • Internal depth
    200 mm
  • Height of installed product
    500 mm
  • Width of installed product
    400 mm
  • Width in division units
    16
  • Thickness of sidewall material
    2 mm
Cover, door
  • Interlockable
    Yes
  • Number of keylock of the door
    1
  • Cover type
    Closed (plain)
  • Door leave
    single
  • Cover type
    Cover
  • Transparent cover or door
    No
Materials
  • Colour
    light grey
  • RAL colour
    RAL 7035 - Light grey
  • Material
    Steel
  • Type of surface treatment
    powder-coated
Installation, mounting
  • Suitable for outdoor use
    No
Settings
  • Enclosure type
    Wall cabinet
Equipment
  • Number of rows
    3
  • Number of keys
    1
  • Number of openings for flange plates
    2
  • Extension possible
    No
Standards
  • European directive WEEE
    concerned
Safety
  • IK protection code against mecanical impacts
    IK10
  • REACH conform
    No
  • RoHS conform
    Yes
  • Halogen free
    Yes
  • Fire resistance
