Description
| Architecture | |
|---|---|
| Fixing mode | section make |
| Functions | |
| Function | can only be used as individual unit |
| Main electrical features | |
| Rated operational voltage Ue | 230 V |
| Frequency | 50;60 Hz |
| Dimensions | |
| Height of installed product | 15.5 mm |
| Length | 75 mm |
| Width of installed product | 19 mm |
| Frequency | |
| Frequency | 50;60 Hz |
| Power | |
| Halogen switching capacity 230V | 0 / 2300 W |
| Max. power with fluo uncompensated lamps | 1000 VA |
| Incandescent bulb power | 0 / 2300 W |
| Capacity | |
| Breaking capacity | 10A 230V AC1 |
| Power supply | |
| Supply voltage | 230 V +10% ; -15% |
| Detection | |
| Detection angle | 360 ° |
| Materials | |
| Colour | white |
| Lighting control | |
| Brightness measurement range | 5 / 1000 Lux |
| Installation, mounting | |
| Mounting type | flush-mounted |
| Maximum Mounting Height | 4 m |
| Connection | |
| Type of contacts | NO |
| Type of connection | with plug-in terminals |
| Settings | |
| Time delayed range | 5s to 30 min |
| Setting | with potentiometers for setting the response brightness and delay time |
| Scope of delivery | |
| Component | with fitting material |
| Safety | |
| Protection index IP | IP21 |
| Protection class | isol.class II |
| Use conditions | |
| Operating temperature | -5/45 °C |
| Storage temperature | -20/60 °C |
| Temperature | |
| Operating temperature | -5/45 °C |
| Identification | |
| Application, usage | Motion detector |
