Motion detector 200°
Rated 3.5/5 based on 11 customer reviews

Motion detector 200°

  • Availability: In Stock
Rs 1,122.00
Hurry! only 0 left in stock!
Ask about this product
Your message has been successfully sent to the store owner!
Add to compare Add to Wishlist
Fixing mode: surface-mounting
Operation mode switch: no
  • can be used as a single unit, main device or extension unit
  • with 2 operating modes: time- and light-dependent switch on or pulse mode
Frequency: 50/60 Hz
Rated operational voltage Ue: 230 V
Operating voltage: 230 V~
Switching current (ohmic): max. 16 A
Max. power with fluo uncompensated lamps: 290 W
Power consumption (standby): 1,2 W
Incandescent bulb power: 1500 W
  • low intrinsic energy requirement
  • energy saving by means of presence and brightness-dependent ON and OFF switching of light
  • Lens setting horizontal ± 80°
  • Lens setting vertical 0 ... 30°
  • with cover elements to limit the detection field
Supply voltage: 230 V +10% / -15%
Frontal detecting distance: 16 m
Side detecting distance: 6 m
Detection angle: 200 °
Detection angle: 200 °
Detection field Ø, on floor: ≈ 16 m
Colour: white
Height of installed product: 2,5 m
Recommended installation height: 2,5 m
Brightness measurement range: 5/1000 Lux
Fluorescent lamps with electronical ballast (EB): 580 W
Response brightness, adjustable: ≈ 5 … 1000 lx
Energy-saving lamps: 10 x 20 W
Fluorescent lamps parallel compensated: 290 W
  • with LED detection and mode indicator
12 V halogen lamps: 1500 VA
230 V incandescent lamps and halogen lamps: 1500 W
Mounting type: surface-mounted
Maximum Mounting Height: 4 m
  • for wall and ceiling mounting, corner installation with adapter
Connection type: quick connect
Type of contacts: 1W + neutral
  • with plug-in terminals
  • with cable entry
Time delayed range: 5s, 15min
Delay time, adjustable: 5 s … 15 mn
  • with potentiometers for setting the response brightness and delay time without dismantling
  • with fitting material
Switch-off delay self-learning: no
  • horizontally rotatable
Protection index IP: IP55
  • with crawl-under protection
Operating temperature: -20 … 55 °C
Storage temperature: -20 to 60 °C
Storage/transport temperature: -20 … 60 °C
Application, usage: Motion detector
Main design line: Motion detectors
Architecture
Fixing mode: surface-mounting
Functions
Operation mode switch: no
  • can be used as a single unit, main device or extension unit
  • with 2 operating modes: time- and light-dependent switch on or pulse mode
Main electrical features
Frequency: 50/60 Hz
Rated operational voltage Ue: 230 V
Voltage
Operating voltage: 230 V~
Electric current
Switching current (ohmic): max. 16 A
Power
Max. power with fluo uncompensated lamps: 290 W
Power consumption (standby): 1,2 W
Incandescent bulb power: 1500 W
  • low intrinsic energy requirement
  • energy saving by means of presence and brightness-dependent ON and OFF switching of light
Camera
  • Lens setting horizontal ± 80°
  • Lens setting vertical 0 ... 30°
Cover, door
  • with cover elements to limit the detection field
Power supply
Supply voltage: 230 V +10% / -15%
Detection
Frontal detecting distance: 16 m
Side detecting distance: 6 m
Detection angle: 200 °
Detection angle: 200 °
Detection field Ø, on floor: ≈ 16 m
Materials
Colour: white
Dimensions
Height of installed product: 2,5 m
Recommended installation height: 2,5 m
Lighting control
Brightness measurement range: 5/1000 Lux
Fluorescent lamps with electronical ballast (EB): 580 W
Response brightness, adjustable: ≈ 5 … 1000 lx
Fluorescent bulbs control
Energy-saving lamps: 10 x 20 W
Fluorescent lamps parallel compensated: 290 W
LED control
  • with LED detection and mode indicator
Incandescent bulbs control
12 V halogen lamps: 1500 VA
230 V incandescent lamps and halogen lamps: 1500 W
Installation, mounting
Mounting type: surface-mounted
Maximum Mounting Height: 4 m
  • for wall and ceiling mounting, corner installation with adapter
Connection
Connection type: quick connect
Type of contacts: 1W + neutral
  • with plug-in terminals
Cable
  • with cable entry
Settings
Time delayed range: 5s, 15min
Delay time, adjustable: 5 s … 15 mn
  • with potentiometers for setting the response brightness and delay time without dismantling
Scope of delivery
  • with fitting material
Equipment
Switch-off delay self-learning: no
  • horizontally rotatable
Safety
Protection index IP: IP55
  • with crawl-under protection
Use conditions
Operating temperature: -20 … 55 °C
Storage temperature: -20 to 60 °C
Storage/transport temperature: -20 … 60 °C
Identification
Application, usage: Motion detector
Main design line: Motion detectors
