Legrand RCD DX³- ID AC 4P 300mA - 80A

Legrand RCD DX³- ID AC 4P 300mA - 80A

Regular price Rs 4,845.00
Regular price Rs 5,235.00 Sale price Rs 4,845.00
Sale Sold out
Tax included.

Type : RCD

SKU : 411667

Tags : RCDs,

Collections : Circuit Breakers, Legrand Protection,

Availability : In Stock

Pickup available at Quatre Bornes

Usually ready in 24 hours

Delivery Available on this product.
We deliver all Mauritius domestic orders within 2-5 business days!

View full details

Legrand RCD DX³- ID AC 4P 300mA - 80A



Warranty: 2 years

Legrand RCDs DX³- ID 4NL - AC Type - 300mA. Affordable, perfect for your build.


DX³-ID four-pole modular differential switch, detects current leaks due to insulation faults and immediately cuts off the power supply to the circuit concerned in the event of accidental contact with the current



  • DX³ four-pole differential switch 400V~ type AC: detects AC component faults
  • High inlet and low outlet via screw terminals
  • Nominal intensity 80A - Sensitivity 300mA - 4 modules
  • Accepts auxiliaries, motorized controls and DX³ connection modules
  • Complies with standard NF EN 61008-1



Technical characteristics

  • Number of pole(s)4
  • Tension400 V
  • Caliber80 A
  • Sensitivity / nominal fault current (IΔn)0.3 A
  • Assigned insulation voltage (Ui)500 V
  • Assigned impulse withstand voltage (Uimp)4 kV
  • Installation methodDIN rail
  • Differential TypeAC
  • SelectiveNo
  • Short-term delayed typeNo
  • Short circuit resistance (Icw)10 kA
  • Shock current holding0.25 kA
  • Voltage typeAC
  • With locking deviceYes
  • Frequency50 Hz
  • Associable auxiliary productsYes
  • Protection class (IP)IP20
  • Width in number of modules4
  • Recessed depth44 mm
  • Ambient temperature in operation-25-60°C
  • Degree of pollution2
  • Flexible cable connection section0.75-35 mm²
  • Rigid cable connection section0.75-50 mm²
  • RAL number (equivalent)7035
  • Explosion-proofNo
  • Width71.2 mm
  • Height83 mm
  • Depth77.8 mm
  • Impact resistance (IK)IK04
  • Storage temperature-40-70°C
  • Nominal voltage (Un)220-440 V
  • Direction of power supplyFrom above or below
  • Indication of the location of the connection terminalsYes
  • Complies with commissioning tests (1000V)Yes
  • ColorGray
  • Halogen freeYes
  • Connection typeScrew terminal
  • Connection typeComb and cable
  • With text area/inscription surfaceYes
  • EAN/Gencode3245064116671
