• Hager Differential Block 2P 30mA - 40A
1 1

Hager Differential Block 2P 30mA - 40A

Hager Differential Block 2P 30mA - 40A

Rs 4,508.00
Rs 4,508.00
Sale Sold out
Tax included.

Type : Differential Block

SKU : HGBD241

Collections : Circuit Breakers, Hager,

Availability : In Stock

Shipping & Returns

Delivery Available on this product.
We deliver all Mauritius domestic orders within 2-5 business days!

View full details

Hager Differential Block 2P 30mA - 40A

Architecture
Neutral position left
Number of poles 2 P
Main electrical features
Rated operational voltage Ue 230 V
Frequency 50 Hz
Rated current
Voltage
Rated insulation voltage 500 V
Rated impulse withstand voltage 4000 V
Electric current
Rated residual operating current 30 mA / 300mA
Dimensions
Depth of installed product 9.2 cm
Height of installed product 7 cm
Width of installed product 3.5 cm
Power
Total power loss under IN 18 W
Tripping
Short-time delayed tripping No
Endurance
Electric endurance in number of cycles 2000
Number of mechanical operations 1000
Capacity
Number of modules 2
Installation, mounting
Tightening torque 2,8Nm
Connection
Connection cross-sect. flexible conductor 16mm²
Connection cross-sect. rigid cable 25mm²
Standards
European directive WEEE concerned
Safety
Protection index IP IP20
Residual current type AC
Use conditions
Operating temperature -5/40 °C
Storage temperature -25/70 °C
