• Hager Contactor 2NO - 2P - 63A
1 1

Hager Contactor 2NO - 2P - 63A

Hager Contactor 2NO - 2P - 63A

Rs 3,750.00
Rs 3,750.00
Sale Sold out
Tax included.

Type : Contactor

SKU : HGESC263

Collections : Circuit Breakers, Hager,

Availability : In Stock

Shipping & Returns

Delivery Available on this product.
We deliver all Mauritius domestic orders within 2-5 business days!

View full details

Hager Contactor 2NO - 2P - 63A

Main electrical features
Rated operational voltage Ue 230 V
Frequency 50 Hz
Rated current 25 A
Voltage
Rated insulation voltage 250 V
Rated impulse withstand voltage 4 kV
Dimensions
Depth of installed product 60 mm
Height of installed product 83 mm
Width of installed product 17.85 mm
Power
Total power loss under IN 5.9 W
Power dissipation per coil 2.9 W
Endurance
Electric endurance in number of cycles 30000
Number of mechanical operations 100000
Capacity
Number of modules 1
Fluorescent bulbs control
Max. power with fluorescent parallel lamps 810 VA
Incandescent bulbs control
Max. power with incandescent lamps 1900 W
Installation, mounting
Tightening torque 1,2Nm
Connection
Connection cross-sect. flexible conductor 1 ; 6mm²
Connection cross-sect. rigid cable 1 ; 10mm²
Type of connection with screw
Type of contacts 2NO
Equipment
Can be accessorized Yes
Standards
European directive WEEE concerned
Safety
Protection index IP 2
Use conditions
Storage temperature -40/80 °C
Temperature
Operating temperature -10/50 °C
