Fixing method | DIN rail |
Main electrical characteristics | |
Rated operational voltage Ue | 230 V |
Rated frequency | 50; 60 Hz |
Dimensions | |
Product installed depth | 64 mm |
Product height installed | 85 mm |
Length | 85 mm |
Product width installed | 35 mm |
Power | |
Consumed strength | 6 VA |
Total power dissipated at IN | 4 W |
Power dissipated by the control | 0.5 W |
Drums | |
Power reserve [year (s)] | ≈ 5 a |
Management of incandescent bulbs | |
P max. with incandescent lamps | 2300 W |
Login | |
Flexible cable connection section | 1; 16mm² |
Rigid cable connection section | 1.5; 10mm² |
Connection type | screw cage |
Number of contacts | 2 |
Contact type | 2 inverters |
Configuration | |
Summer / winter change | automatic |
Programming finesse | 1 min |
Programmer type | electronic |
Programming cycle | 2X7J |
Equipment | |
Number of ways | 2 |
Power reserve | 5 years |
use | |
Cycle | weekly |
security | |
IP protection class | IP20 |
Terms of use | |
Running precision | 1 |
Storage temperature | -20/70 ° C |
