Description
| Architecture | |
|---|---|
| Fixing mode | Din-Rail |
| Functions | |
| Function | Keylock by means of blocking key |
| Configuration | |
| Switch mode | change-over contact |
| Main electrical features | |
| Rated operational voltage Ue | 230 V |
| Frequency | 50 Hz |
| Voltage | |
| Supply voltage | 230V AC |
| Dimensions | |
| Depth of installed product | 64 mm |
| Height of installed product | 85 mm |
| Length | 58.1 mm |
| Width of installed product | 35 mm |
| Dimensions (W x H x D) | 35/85/64 mm |
| Power | |
| Power consumed | 6 VA |
| Total power loss under IN | 2 W |
| Power dissipation per coil | 0.5 W |
| Capacity | |
| Breaking capacity | 16A 250V AC1 |
| Capacity | |
| Number of modules | 2 |
| Battery | |
| Power reserve [years] | ≈ 5 a |
| Charging time of the power reserve in hours | 0 |
| Incandescent bulbs control | |
| Max. power with incandescent lamps | 2300 W |
| Connection | |
| Connection cross-sect. flexible conductor | 1 ; 6mm² |
| Connection cross-sect. rigid cable | 1,5 ; 10mm² |
| Type of connection | with screw |
| Number of contacts | 1 |
| Type of contacts | 1 changeover |
| Type of connection | with screw terminals |
| Settings | |
| Summer / Winter time change | automatic |
| Shortest switching time | 1 mn |
| Type of programming | digital |
| Programming cycle | 1X7D. |
| Equipment | |
| Number of channels | 1 |
| Supply failure reserve | 5 years |
| With holidays program | No |
| DCF | No |
| Use | |
| Cycle | weekly |
| Safety | |
| Protection index IP | IP20 |
| Use conditions | |
| Operating temperature | -5/45 °C |
| Working accuracy | 1,5 |
| Storage temperature | -20/70 °C |
| Temperature | |
| Operating temperature | -5/45 °C |
