Delay ON Timer


Price:
Sale priceRs 3,140.00 MUR Regular priceRs 3,329.00 MUR

Description

Architecture
Fixing mode DIN rail type O (symmetrical)
Functions
Function Functions: On delay, Off delay, single shot leading edge;single shot trailing edge, pulse shaping, flashing symmetrically, contact open;closed
Configuration
Switch mode change-over contact, usable as NC or NO
Main electrical features
Frequency 50;60 Hz
Voltage
Supply voltage 12, 24, 48 or 230V
Dimensions
Depth of installed product 58 mm
Height of installed product 85 mm
Length 64 mm
Width of installed product 17.5 mm
Dimensions (W x H x D) 17.5/85/58 mm
Power
Power consumed 15 VA
Power consumption (operation) 1.2 W
Total power loss under IN 2 W
Power dissipation per coil 0.5 W
Capacity
Breaking capacity 8A 230V AC1
Capacity
Number of modules 1
Incandescent bulbs control
Max. power with incandescent lamps 450 W
Installation, mounting
Mounting type din-Rail
Connection
Connection cross-sect. flexible conductor 1 ; 6mm²
Connection cross-sect. rigid cable 1,5 ; 10mm²
Type of connection with screw
Number of contacts 1
Type of contacts 1 changeover
Type of connection with screw terminals
Settings
Time delayed range 0.1 s... 10 h
Setting with 2 potentiometers for setting of delay time
Safety
Protection index IP IP40
Use conditions
Operating temperature -10/50 °C
Storage temperature -40/70 °C
Temperature
Operating temperature -20/50 °C
