Camera

Image Sensor

2MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Pixel

2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s–1/100000 s

NTSC: 1/30 s–1/100000 s

S/N Ratio

> 65 dB

Min. Illumination

0.02Lux/F1.7, 30IRE, 0Lux IR on

Illumination Distance

60m (196.9 ft)

Illuminator On/Off Control

Auto;

Illuminator Number

4 (IR light)

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens

Lens Type

Motorized Vari-focal

Auto Focus

N/A

Mount Type

φ14

Focal Length

2.7 mm-12 mm

Max. Aperture

F1.7

Field of View

Diagonal: 38°– 125°

Horizontal: 33°–102°

Vertical: 19°– 53°

Iris Type

Fixed

Close Focus Distance

1.2 m (3.9 ft)

DORI Distance

2.7mm: D: 49.7 m (163.1 ft); O: 19.9 m (65.3 ft); R: 9.9 m

(32.5 ft); I: 5 m(16.4 ft)

12mm: D: 82.8 m (271.7 ft); O: 33.1 m (108.6 ft); R: 16.6 m (54.5 ft); I: 8.3 m(27.2 ft)

Video

Frame Rate

CVI:

1080P@25/30fps;

720P@25/30fps;

AHD:

1080P@25/30fps;

720P@25/30fps;

TVI:

1080P@25/30fps;

720P@25/30fps;

CVBS: 960H

Resolution

1080P (1920×1080); 720P (1280×720); 960H (960× 576/960×480)

Day/Night

Auto switch by ICR

BLC

BLC/DWDR/HLC

White Balance

Auto/Area WB

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Mirror

Yes

Privacy Masking

Off/On (8 area, rectangle)

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Audio Input

One channel built-in mic

Power

Power Supply

POC (only CVI)/12V±30% DC

Power Consumption

Max7.2W (12V DC, IR on); PoC (AT)

Environment

Operating Temperature

–30°C to +60°C (–22°F to 140°F);﹤ 95%

(non-condensation)

Storage Temperature

–30°C to +60°C (–22°F to 140°F);﹤ 95%

(non-condensation)

Protection Grade

IP67

Structure

Casing

Mental throughout the whole casing

Camera Dimensions

209.9 mm × 90.4 mm × 90.4 mm (8.26" × 3.56" × 3.56")

Net Weight

0.57 Kg (1.3 lb)

Gross Weight

0.72 Kg (1.6 lb)
