Description
Technical Characteristics |
Frequency: | 50 Hz |
Rated operational voltage Ue: | 400 V |
Rated insulation voltage: | 440 V |
Command voltage AC: | 230 V |
Rated impulse withstand voltage: | 4 kV |
Acceptable current load with AC7 category A: | 40 A | 63A |
Acceptable current load with AC7 category B: | 25 A | 32A |
Thermal rated current outside of housings: | 40 A | 63A |
Inrush power absorbed: | 62,5 W |
Operating consumption: | 5,75 W |
Contact rating with 230 V in AC7 category A: | 7,3 kW | 11,6 kW |
Contact rating with 230 V in AC7 category B: | 2,6 kW | 3,3 kW |
Contact rating with 400 V in AC7 category A: | 22 kW | 35 kW |
Contact rating with 400 V in AC7 category B: | 7,8 kW |
Power loss per contact: |
3,2 W | 5.0 W
|
Total power loss under IN: | 12,15 W |
Power dissipation per coil: | 0,5 W |
Time of response when closing: | 25 ms |
Time of response when opening: | 20 ms |
Winding resistance: | 770 Ω |
Electric endurance in number of cycles: | 30000 |
Number of mechanical operations: | 1000000 |
Depth of installed product: | 60 mm |
Height of installed product: | 85 mm |
Width of installed product: | 54 mm |
Max. load fluorescent lamp: | 1900 VA | 3000VA |
Max. power with fluorescent parallel lamps: | 1300 VA | 2100VA |
Fluorescent lamps in duo circuit: | 3000 VA | 4700VA |
Max. power with incandescent lamps: | 4000 W | 6500W |
Tightening torque: | Coil: 2,5Nm, Power: 3,5Nm |
Max cable connect. cross section (flexible) for control: | 1 to 6 mm² |
Connection cross-section of the control cable solid: | 1 to 10 mm² |
Connection cross-sect. rigid cable: | 4 /25mm² |
Connection cross-sect. flexible conductor: | 4 / 16mm² |
Type of connection: | with screw |
Number of contacts: | 2 |
Type of contacts: | 2NC |
Can be accessorized: | yes |
Local operation/hand operation: | no |
European directive WEEE: | concerned |
Protection class: | isol.class II |
Protection index IP: | 2 |
Storage temperature: | -40 to 80 °C |
