Description
Architecture | |
---|---|
Fixing mode | Din-Rail |
Functions | |
Power reserve | ≈ 200 h |
Configuration | |
Switch mode | NO contact |
Main electrical features | |
Rated operational voltage Ue | 210 / 230 V |
Frequency | 50 Hz |
Voltage | |
Supply voltage | 230V AC |
Dimensions | |
Depth of installed product | 60 mm |
Height of installed product | 80 mm |
Width of installed product | 18 mm |
Dimensions (W x H x D) | 18/80/60 mm |
Power | |
Power consumed | 0.5 VA |
Power consumption (operation) | 0.5 VA |
Total power loss under IN | 1 W |
Power dissipation per coil | 0.5 W |
Capacity | |
Breaking capacity | 16A 250V AC1 |
Capacity | |
Number of modules | 1 |
Battery | |
Charging time of the power reserve in hours | 120 |
Incandescent bulbs control | |
Max. power with incandescent lamps | 900 W |
Installation, mounting | |
Mounting type | din-Rail |
Connection | |
Connection cross-sect. flexible conductor | 1 ; 4mm² |
Connection cross-sect. rigid cable | 1 ; 4mm² |
Type of connection | with screw |
Number of contacts | 1 |
Type of contacts | 1 changeover |
Type of connection | with screw terminals |
Settings | |
Summer / Winter time change | manual |
Shortest switching time | 15 mn |
Type of programming | analog |
Programming cycle | 24H |
Setting | Setting via day dial |
Equipment | |
Number of channels | 1 |
Supply failure reserve | 200 h |
Use | |
Cycle | daily |
Safety | |
Protection index IP | IP20 |
Use conditions | |
Operating temperature | -10/55 °C |
Working accuracy | 1 |
Storage temperature | -10/55 °C |
Temperature | |
Operating temperature | -10/55 °C |
