ABB - Switch Disconnector (Isolator) 2Pole (2P) - 100A

These devices are suitable for commanding loads and they are realized according EN 60947-3 and EN 60669-1 respectively. Fast removal without dismantling of the busbar. Captive screws with recessed/slotted head. Pozidrive size 2. Add-on of up to 3 auxiliary contact S2C-H6R possible Integrated lay-on edge for labeling system ILS. Locking device as accessories for unauthorized ON/OFF. Approval: VDE, CCC, KEMA

• Standards: IEC/EN 60947-3

• Rated Voltage (U_r): 400 V, 12 V Minimum

• Rated Operational Voltage: 230 / 400 V AC

• Input Voltage Type: AC

• Rated Conditional Short-Circuit Current (I_nc): 25 kA

• Rated Service Short-Circuit Breaking Capacity (I_cs): 25 kA

• Power Loss: 0.6 W at Rated Operating Conditions per Pole 0.3 W

• Number of Poles: 2

• Number of Contacts CO: 0

• Number of Contacts NC: 0

• Number of Contacts NO: 2

• Product Range: Switch-disconnector E202

• Switch Type: Off

• Recommended Screw Driver: Pozidriv 2

• Accessories Available: Yes

• Cover Color: Grey
